ZHHW-85恒温恒湿试验箱
功能简介
l 恒温恒是试验箱可对电气、电子、家用电器、汽车、摩托车、化工及其它产品零部件及材料在恒定湿热的情况下,进行高温、低温以及狡辩湿热试验。检验其各项性能指标及适应性。
本设备符合
l GB/T10586-89 Test conditions of thermal -humidity test chamber
l GB/T2423.1-2001 GB/T2423.1-2001 Test method of low temperature test chamber
l GB/T2423.2-2001 GB/T2423.2-2001 Test method of high temperature test chamber
l GB/T2423.3-93 GB/T2423.3-93 Test method of thermal-humidity test chamber
规格与技术参数
型号 Model | ZHHW-85 | ZHHW -85A | ZHHW -85B | ZHHW-85C | ZHHW-85D |
内部尺寸 Internal Dimensions WxHxD(cm) | 400×500×500 | 500×600×750 | 600×800×850 | 850×1000×1000 | 1000×1000×1000 |
外形尺寸External Dimensions WxHxD(cm) | 950×930×1620 | 1050×1070×1870 | 1150×1430×1970 | 1350×1430×2120 | 1500×1430×2120 |
内箱容积 | 100L | 225L | 408L | 800L | 1000L |
温度上限Upper temperature limit | +150℃/+200℃ | ||||
温度下限Lower temperature limit | 0℃、-20℃、-40℃、-70℃ | ||||
湿度范围 Humidity range | 20%~98%RH | ||||
温湿度精度/均匀度 Humiture precision/uniformity | ±0.1℃; ±0.1%RH/±1.0℃; ±2%RH | ||||
升温/降温时间 Warming up/cooling down time | 升温约Warming about 4℃/MIN 降温约 Cooling about 1℃/MIN | ||||
温湿度控制器 Control panel | 韩国进口TEMI系列温湿度控制器 South Korea”TEMI”series temperature and humidity controller | ||||
制冷机组 Compressor | 法国进口泰康压缩机组(环保型) Franceas “Tecumseh”Brand | ||||
制冷机组 | 法国进口泰康压缩机组(环保型) Franceas”Tecumseh”Brand | ||||
加湿器 | KD 不锈钢发生器 Stainless deviser | ||||
冷却方式 | 风冷或水冷 Air cooling/water cooling | ||||
加热器 | 镍锘合金加热单元 Nichrome heater | ||||
安全保护措施 Protection device | 超温、过载、超压、漏电、断水、短路、电源缺相、错相保护 Over heating,over loading,over pressure,leakage,water-break,cutting off and power phase dislocation protect | ||||
外壳材料 Housing materials | SUS304拉丝不锈钢板或钢板静电喷塑 Brushed or static plastic spraying on steel plates | ||||
内壁材料 Inner material | SUS304不锈钢 Stainless plates | ||||
保温材料 Insulation material | 超细玻璃棉或聚氨酯泡沫 Extra-fine glasswool or Polyurethane foam | ||||
电源 Power | 220V/380V±10%,50Hz,3P+N+G | ||||
产品标准Standards | Gb10586:湿热试验箱技术条件 Thermal-humidity specification Db10589: 低温试验箱技术条件 Low temperature specification | ||||
试验方式 Testing method | Gb/T2423.1、 Gb/T2423.9、Gjb150.4 |
智品汇售后服务
设备售后政策:
*设备保修期:一年
*售后电话:4008166687
1、我司组建了一批有丰富经验的现场工程师和高级技师,对设备出现的任何问题都能够在最快的时间内做出反应,进行售后维护。
2、新产品交付一周内,我司售后技术部的工作人员会根据客户提供的联系方式和地址,到客户所在地对设备进行安装售后培训工作。
3、所有有关于产品质量投诉,在1小时内经予答复,省内3~5小时、省外24~48小时内赶到现场,并根据投诉的情况确定处理措施,进行售后维护。
4、为更好的解决客户的困难和疑虑,我司承诺所有维修人员随叫随到。
5、保质期内有关于产品质量引发的费用,由我司承担。
6、保质期内由于贵方的使用不当,或者是自然环境造成的我方免费提供维修,维修所用的材料和配件均只收成本价。
